  Intel Navy Pier Platform (Intel ATOM N270 Processor)


ESM-PCS01


¡Ø Platform specification ¡Ø
¡Ü Processor
  ¢º Intel ATOM N270 1.6GHz, 2.5W
¡Ü Main Chipset
  ¢º North Bridge : Intel 945GSE (Built-in Graphics)
  ¢º South Bridge : Intel ICH7-M
¡Ü Memory
  ¢º SODIMM Socket for System Memory (DDR2)
¡Ü Flash ROM
  ¢º 8Mbit SPI ROM for BIOS
¡Ü Super I/O
  ¢º ITE IT8718F (PQFP-128)
¡Ü Ethernet
  ¢º  RealTek RTL8111D-GR(PCIE), two Gigabit Ethernet
  ¢º  RealTek RTL81103EL-GR(PCIE), one Fast Ethernet
¡Ü Main Clock
  ¢º IDTCV179BNLG (QFN-64)
¡Ü PWM (Power)
  ¢º TI TPS51120RHBR for 3.3V/5V Main Power
  ¢º Semtech SC454MLTRT for CPU power
  ¢º Semtech SC415MLTRT for 1.5V/1.05V power
  ¢º Semtech SC486IMLTRT for DDR2 Memory power
¡Ü I/O Port
  ¢º 2*USB2.0 / 2*RJ45(RA) / 1*RJ45(ST) / 1*SATA / 1*VGA / 1*UART(RJ25)
¡Ü Storage Device
  ¢º 2.5" SATA HDD
¡Ü OS
  ¢º CentOS Linux & Windows XP
¡Ü Thernal Solution
  ¢º FANless with Heatsink
¡Ü ACPI & APM
  ¢º No Power Management
¡Ü Power Supply
  ¢º DC12V ´ÜÀÏÀü¿ø »ç¿ë, No DC Power Switch
¡Ü Operating Condition
  ¢º 0 ~ 45¢ªC (0 ~ 90% humidity)
¡Ü BIOS : AMI Legacy BIOS (AMIBIOS8) by Xannex Technologies
